| Main parameter | CPU | Quad-core Cortex-A53 |
| GPU | Mali-450MP2 supports OpenGL ES1.1/2.0 and OpenVG1.1 | |
| Memory | 1G/2G | |
| Storage | EMMC 8G/16G/32G/64G | |
| System | Android9.0 /LINUX Debian | |
| USB | 1 set of USB 2.0 (OTG USB TYPE C interface) | |
| Communication interface | UART | 1 debug Indicates the debugging interface |
| WIFI | SDIO3.0 Wifi5 1T1R 2.4G/5G +5.0 BT IEEE802.11a /b/g/n/ac standard | |
| Display interface | HDMI | The maximum resolution of one HDMI port is 4K |
| Power interface | Power supply | TYPE C Power Supply 5V 2A adapter power supply |
| Other | Audio module | 5.8G wireless audio module |
| Distribution key | WIFI KEY | |
| Upgrade | Upgrade the UBOOT button | |
| Power key | Pwron Power button | |
| Video processor | Video codec | Support 4K VP9 and 4K 10bits H265/H264 video decoding, up to 60fps 1080P multi-format video decoding (WMV, MPEG-1/2/4, VP9, H.264, H.265) 1080P video encoding, Support for H.264/H.265 video post-processing: anti-interleaving, noise removal, edge/detail/color optimization |
Support Android Android7.1, Ubuntu, Fedora, Debian, Linux+QT and other operating systems, mainly for the Internet of Things intelligent gateway, multimedia player box, TVBOX video projector and other industry customization market
