| Input signal | HDMI signal | Support mode 480p、720p、1080p |
| HDMI 1.4b | ||
| HDCP 1.4/2.2 | ||
| Output display interface | LVDS | Hardware connection output mode 1ch-8bit、2ch-8bit、1ch-6bit、2ch-6bit。 |
| Output data format RGB888 RGB666 | ||
| resolution 1024*768 1366*768 1440*900 1280*800 1280*1024 1920*1080 | ||
| EDP | Hardware connection output mode 2*LAN 4*LAN | |
| Output data format RGB888 | ||
| resolution 1920*1080 2560*1440 | ||
| Audio power amplifier | Power amplifier type | Class D Class D |
| Load impedance | 4Ω | |
| Power Consumption | 2x3W | |
| Sonic shell | -95db | |
| Power supply | Input voltage | 10-14v |
| Operating power consumption | 2W | |
| Standby power consumption | 0.4W | |
| LCM voltage | 3.3v/5v/12v | |
| Power operation | Working mode, standby mode | |
| TP | USB-TP | Support USB capacitor touch interface |
| CTP | Support 10.1 “capacitive touch | |
| Others | OSD language | Simplified Chinese and English |
| OSD function | Automatic adjustment, color adjustment, image adjustment and other support DDC/CI protocol |
The main application markets include medical equipment, industrial display, tablet computer, IT display, TV, commercial display, development display, etc
